HDMI & Serial Display Modules
B22C28038Q-01 – 2.76 Inch 480x480 IPS TFT LCD Display with HDMI Driver Board
B22C28038Q-01 is a 2.76-inch IPS TFT LCD display with 480 x 480 resolution and a...
B22C37002Q-01 – 3.71 Inch 260x960 IPS TFT LCD Display with HDMI Driver Board
B22C37002Q-01 is a 3.71-inch IPS TFT LCD display with 260 x 960 resolution and a...
B26C70982N-01 – 6.75 Inch 480x1280 IPS TFT LCD Display with HDMI Driver Board
B26C70982N-01 is a 6.75-inch IPS TFT LCD display with 480 x 1280 resolution and a...
B22C45194Q-01 – 4.58 Inch 320x960 IPS TFT LCD Display with HDMI Driver Board
B22C45194Q-01 is a 4.58-inch IPS TFT LCD display with 320 x 960 resolution and a...
B26C43039N-01 – 4.3 Inch 480x272 IPS TFT LCD Display with HDMI Driver Board
B26C43039N-01 is a 4.3-inch IPS TFT LCD display with 480 x 272 resolution and a...
B21C21001Q-01 – 2.1 Inch 480x480 IPS TFT LCD Display with HDMI Driver Board
B21C21001Q-01 is a 2.1-inch IPS TFT LCD display with 480 x 480 resolution and a...
HDMI & Serial Display Modules – Plug-and-Play TFT LCD Solutions
HDMI and serial display modules combine LCD screens with driver boards. Supported interfaces include HDMI, VGA, AV, UART, RS485, and CAN. Plug-and-play, no need to develop your own driver. Suitable for industrial HMI, energy storage, medical devices, and smart equipment. Sizes from 0.96" to 15.6". No MOQ for custom orders. Small-batch customization and mass production supported.
| Inquire | Size | P/N | Resolution | Interface | Display Type | Viewing Angle | Luminance | OD Size | Op.Temp | St.Temp | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Inquire | 2.1" | B21C21001Q-01 | 480 × 480 | RGB | IPS | — | 360 nits | 56.18 × 59.718 × 2.2 | -10 to +60°C | -20 to +70°C | PDF ↓ |
| Inquire | 2.76" | B22C28038Q-01 | 480 × 480 | RGB | IPS | — | 300 nits | 73.03 × 76.48 × 2.3 | -20 to +70°C | -30 to +80°C | PDF ↓ |
| Inquire | 3.71" | B22C37002Q-01 | 260 × 960 | RGB | IPS | — | 300 nits | 25.3 × 98.89 × 1.65 | -20 to +70°C | -30 to +80°C | PDF ↓ |
| Inquire | 4.3" | B26C43039N-01 | 480 × 272 | RGB | IPS | — | 500 nits | 105.32 × 67.02 × 2.9 | -20 to +70°C | -30 to +80°C | — |
| Inquire | 4.58" | B22C45194Q-01 | 320 × 960 | RGB | IPS | — | 300 nits | 41.57 × 118.8 × 2.5 | -20 to +70°C | -30 to +80°C | PDF ↓ |
| Inquire | 6.75" | B26C70982N-01 | 480 × 1280 | MIPI | IPS | — | 420 nits | 66.02 × 171.69 × 4.20MM | -20 to +70°C | -30 to +80°C | — |
2.76 Inch 480x480 IPS TFT LCD Display with HDMI Driver Board
2.76" 480 × 480 RGB IPS TFT display, 300 nits, with HDMI driver board.
3.71 Inch 260x960 IPS TFT LCD Display with HDMI Driver Board
3.71" 260 × 960 RGB IPS TFT display, 300 nits, with HDMI driver board.
4.3 Inch 480x272 IPS TFT LCD Display with HDMI Driver Board
4.3" 480 × 272 RGB IPS TFT display, 500 nits, with HDMI driver board.
4.58 Inch 320x960 IPS TFT LCD Display with HDMI Driver Board
4.58" 320 × 960 RGB IPS TFT display, 300 nits, with HDMI driver board.
6.75 Inch 480x1280 IPS TFT LCD Display with HDMI Driver Board
6.75" 480 × 1280 MIPI IPS TFT display, 420 nits, with HDMI driver board.
