Touch Screen Displays
B25C24040Q-01-C – 2.4 Inch 240x320 MCU High-Brightness IPS TFT LCD Display with Capacitive Touch
B25C24040Q-01-C is a 2.4-inch IPS TFT LCD display with 240 x 320 resolution and a...
B26C35076Q-01-C – 3.5 Inch 320x480 MCU IPS TFT LCD Display with Capacitive Touch
B26C35076Q-01-C | 250 nits | MCU interface
B26C55263Q-01 – 5.5 Inch 1080x1920 MIPI High-Brightness IPS TFT LCD Display with In-Cell Touch
B26C55263Q-01 is a 5.5-inch IPS TFT LCD display with 1080 x 1920 resolution and a...
B24C80055Q-01-C – 8.0 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B24C80055Q-01-C | 300 nits | MIPI interface
B26C122002Q-01 – 12.2 Inch 1600x2400 MIPI IPS TFT LCD Display with In-Cell Touch
B26C122002Q-01 | 350 nits | MIPI interface
B24C11002Q-01-C – 10.95 Inch 1200x1920 MIPI IPS TFT LCD Display with In-Cell Touch
B24C11002Q-01-C | 350 nits | MIPI interface
B24C10642Q-01-C – 10.1 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B24C10642Q-01-C | 260 nits | MIPI interface
B26C10663Q-01-C – 10.1 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B26C10663Q-01-C | 280 nits | MIPI interface
B26C80072Q-01-C – 8.0 Inch 1200x1920 MIPI IPS TFT LCD Display with Capacitive Touch
B26C80072Q-01-C | 400 nits | MIPI interface
B22C80049Q-01-C – 8.0 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B22C80049Q-01-C | 280 nits | MIPI interface
B22C55246Q-02-C – 5.45 Inch 720x1440 MIPI IPS TFT LCD Display with Capacitive Touch
B22C55246Q-02-C | 350 nits | MIPI interface
B25C55255Q-01-C – 5.5 Inch 480x960 MIPI IPS TFT LCD Display with Capacitive Touch
B25C55255Q-01-C | 350 nits | MIPI interface
B25C80063Q-02-C – 8.0 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B25C80063Q-02-C | 450 nits | MIPI interface
B21C50682Q-02-C – 5.0 Inch 720x1280 MIPI IPS TFT LCD Display with Capacitive Touch
B21C50682Q-02-C | 400 nits | MIPI interface
B23C40298Q-02-C – 3.97 Inch 480x800 MIPI IPS TFT LCD Display with Capacitive Touch
B23C40298Q-02-C | 380 nits | MIPI interface
B26C45199N-01-C – 4.5 Inch 480x854 MIPI IPS TFT LCD Display with Capacitive Touch
B26C45199N-01-C | 350 nits | MIPI interface
B24C40306N-01-C – 3.97 Inch 480x800 MIPI IPS TFT LCD Display with Capacitive Touch
B24C40306N-01-C | 300 nits | MIPI interface
B26C40314N-01-C – 3.97 Inch 480x800 RGB IPS TFT LCD Display with Capacitive Touch
B26C40314N-01-C | 300 nits | RGB interface
B22C40290N-01-C – 3.97 Inch 480x800 MIPI IPS TFT LCD Display with Capacitive Touch
B22C40290N-01-C | 290 nits | MIPI interface
B25C40310Q-01-C – 3.97 Inch 480x800 MIPI IPS TFT LCD Display with In-Cell Touch
B25C40310Q-01-C | 380 nits | MIPI interface
Touch Screen Displays – Capacitive & Resistive TFT LCD Modules
Touch screen displays include capacitive and resistive touch options. Capacitive touch supports multi-touch, high sensitivity, and durable cover glass. Resistive touch is suitable for stylus, glove, or industrial environments. Sizes from 2.4" to 15.6", with optional high brightness, wide temperature, and anti-UV / ceramic sintered ink cover glass. Both frame bonding and full lamination are available, with optional driver board integration. No MOQ for custom orders. Small-batch customization and mass production supported.
| Inquire | Size | P/N | Resolution | Interface | Display Type | Viewing Angle | Luminance | OD Size | Op.Temp | St.Temp | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Inquire | 1.3" | B24C13013Q-01-C | 240 × 240 | SPI | IPS | — | 300 nits | 35.3 × 35.2 × 3.41(TLCM) 26.17 × 29.22 × 1.88/(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 2.4" | B25C24040Q-01-C | 240 × 320 | MCU | IPS | — | 1000 nits | 47.72 × 65.86 × 3.17 | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 2.8” | B22C28046Q-01-C | 480 × 640 | MIPI | IPS | — | 350 nits | 46.5 × 65.05 × 1.63 | -20°C-70°C | -30°C-80°C | — |
| Inquire | 2.8” | B24C28048N-01-C | 240 × 320 | MCU | IPS | — | 260 nits | 78.86 × 99.97 × 3.8(TLCM) 50.0 × 69.2 × 2.35(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 2.95” | B22C30006Q-01-C | 360 × 640 | RGB | IPS | — | 300 nits | 82.95 × 86.95 × 3.83(TLCM) 42.6 × 74.5 × 2.2(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 3.5" | B23C35063Q-01-C | 640 × 480 | MIPI | IPS | — | 350 nits | 80.0 × 67.2 × 3.58(TLCM) 74.5 × 62.4 × 2.35(LCM) | -20°C-70°C | -30°C-80°C | — |
| Inquire | 3.5" | B26C35073Q-01-C | 640 × 480 | MIPI | IPS | — | 500 nits | 81.4 × 67.9 × 4.38(TLCM) 78.0 × 64.5 × 2.5(LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 3.5" | B26C35076Q-01-C | 320 × 480 | MCU | IPS | — | 250 nits | 56.48 × 84.71 × 3.75(TLCM) 54.48 × 84.71 × 2.3(LCM) | -10°C-60°C | -20°C-70°C | — |
| Inquire | 3.95" | B22C40284Q-03-C | 480 × 480 | MIPI | IPS | — | 300 nits | 83.6 × 83.6 × 3.32(TLCM) 74.56 × 76.54 × 2.1(LCM) | -20°C-60°C | -30°C-70°C | PDF ↓ |
| Inquire | 3.95" | B26C40315Q-01-C | 480 × 480 | RGB | IPS | — | 300 nits | 86.0 × 86.0 × 3.38(TLCM) 54.48 × 84.71 × 2.3(LCM) | -20°C-60°C | -30°C-70°C | PDF ↓ |
| Inquire | 3.95" | B26C40316Q-01-C | 480 × 480 | MIPI | IPS | — | 300 nits | 86.0 × 86.0 × 3.38(TLCM) 54.48 × 84.71 × 2.3(LCM) | -20°C-60°C | -30°C-70°C | — |
| Inquire | 3.97" | B22C40290N-01-C | 480 × 800 | MIPI | IPS | — | 290 nits | 61.6 × 100.9 × 3.57(TLCM) 57.14 × 96.85 × 2.2(LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 3.97" | B23C40298Q-02-C | 480 × 800 | MIPI | IPS | — | 380 nits | 70.7 × 105.49 × 3.47(TLCM) 57.14 × 96.85 × 2.2(LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 3.97" | B24C40306N-01-C | 480 × 800 | MIPI | IPS | — | 300 nits | 70.0 × 108.0 × 3.76(TLCM) 57.14 × 96.85 × 2.2(LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 3.97" | B25C40310Q-01-C | 480 × 800 | MIPI | IPS | — | 380 nits | 70.7 × 105.49 × 3.30(TLCM) 54.14 × 92.65 × 2.03(LCM) | -20°C-70°C | -30°C-80°C | — |
| Inquire | 3.97" | B26C40314N-01-C | 480 × 800 | RGB | IPS | — | 300 nits | 60.0 × 158.7 × 5.07(TLCM) 57.14 × 96.85 × 2.2(LCM) | -10°C-60°C | -20°C-70°C | — |
| Inquire | 4.5" | B26C45199N-01-C | 480 × 854 | MIPI | IPS | — | 350 nits | 64.8 × 120.0 × 3.16(TLCM) 58.21 × 106.06 × 1.68(LCM) | -10°C-60°C | -20°C-70°C | — |
| Inquire | 5.0" | B21C50682Q-02-C | 720 × 1280 | MIPI | IPS | — | 400 nits | 80.86 × 129.16 × 3.33(TLCM) 65.6 × 119.4 × 1.86（LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 5.45 | B22C55246Q-02-C | 720 × 1440 | MIPI | IPS | — | 350 nits | 69.3 × 146.7 × 3.13(TLCM) 64.32 × 130.58 × 1.51(LCM) | -20°C-70°C | -30°C-80°C | — |
| Inquire | 5.5" | B25C55255Q-01-C | 480 × 960 | MIPI | IPS | — | 350 nits | 73.84 × 144.35 × 3.51(TLCM) 64.32 × 130.58 × 2.21(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 5.5" | B26C55263Q-01 | 1080 × 1920 | MIPI | IPS | — | 950 nits | 70.24 × 128.10 × 1.52 | -20°C-70°C | -30°C-80°C | — |
| Inquire | 6.1" | B25C61001N-01-C | 280 × 1424 | MIPI | IPS | — | 300 nits | 43.5 × 178.0 × 6.32(TLCM) 36.39 × 136.86 × 4.35(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 6.75" | B22C70945Q-01-C | 480 × 1280 | MIPI | IPS | — | 400 nits | 78.69 × 207.13 × 6.30(TLCM) 66.02 × 171.69 × 4.2(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 7.0" | B24C70961Q-02-C | 1024 × 600 | MIPI | IPS | — | 400 nits | 195.8 × 125.61 × 8.25(TLCM) 165 × 100 × 5.3MM(LCM) | -20°C-70°C | -30°C-80°C | PDF ↓ |
| Inquire | 8.0" | B22C80049Q-01-C | 800 × 1280 | MIPI | IPS | — | 280 nits | 123.0 × 193.5 × 4.65(TLCM) 114.6 × 184.16 × 2.6(LCM) | -10°C-60°C | -20°C-70°C | — |
| Inquire | 8.0" | B24C80055Q-01-C | 800 × 1280 | MIPI | IPS | — | 300 nits | 128.6 × 196.3 × 4.65(TLCM) 114.6 × 184.16 × 2.6(LCM) | -10°C-60°C | -20°C-70°C | PDF ↓ |
| Inquire | 8.0" | B25C80063Q-02-C | 800 × 1280 | MIPI | IPS | — | 450 nits | 122.6 × 247.60 × 4.63(TLCM) 114.6 × 184.16 × 2.6(LCM) | -10°C-60°C | -20°C-70°C | — |
| Inquire | 8.0" | B26C80072Q-01-C | 1200 × 1920 | MIPI | IPS | — | 400 nits | 134.8 × 204.1 × 3.63(TLCM) 114.12 × 183.18 × 2.18(LCM) | -10°C-50°C | -20°C-60°C | — |
| Inquire | 10.1" | B24C10642Q-01-C | 800 × 1280 | MIPI | IPS | — | 260 nits | 166.06 × 242.28 × 4.7(TLCM) 143.0 × 228.6 × 2.65(LCM) | -10°C-50°C | -20°C-60°C | — |
| Inquire | 10.1" | B26C10663Q-01-C | 800 × 1280 | MIPI | IPS | — | 280 nits | 248.4 × 187.4 × 4.8(TLCM) 143.0 × 228.6 × 2.75(LCM) | -10°C-50°C | -20°C-60°C | — |
| Inquire | 10.95 | B24C11002Q-01-C | 1200 × 1920 | MIPI | IPS | — | 350 nits | 152.52 × 244.1 × 2.12 | -10°C-50°C | -20°C-60°C | PDF ↓ |
| Inquire | 12.2 | B26C122002Q-01 | 1600 × 2400 | MIPI | IPS | — | 350 nits | 177.43 × 266.15 × 1.93 | -10°C-50°C | -20°C-60°C | PDF ↓ |
B25C24040Q-01-C – 2.4 Inch 240x320 MCU High-Brightness IPS TFT LCD Display with Capacitive Touch
2.4" 240 × 320 MCU IPS TFT LCD display, 1000 nits.
B26C35076Q-01-C – 3.5 Inch 320x480 MCU IPS TFT LCD Display with Capacitive Touch
3.5" 320 × 480 MCU IPS TFT LCD display, 250 nits.
B26C55263Q-01 – 5.5 Inch 1080x1920 MIPI High-Brightness IPS TFT LCD Display with In-Cell Touch
5.5" 1080 × 1920 MIPI IPS TFT LCD display, 950 nits.
B24C80055Q-01-C – 8.0 Inch 800x1280 MIPI IPS TFT LCD Display with Capacitive Touch
8.0" 800 × 1280 MIPI IPS TFT LCD display, 300 nits.
