B24C70961Q-02-C – 7.0 Inch 1024x600 MIPI IPS TFT LCD Display with Capacitive Touch
No image available
No image available

B24C70961Q-02-C is a 7.0-inch IPS TFT LCD display with 1024 x 600 resolution and a MIPI panel interface. The specified brightness is 400 nits. The module includes capacitive touch.

B24C70961Q-02-C – 7.0 Inch 1024x600 MIPI IPS TFT LCD Display with Capacitive Touch
Share
Product description
  • Storage Temperature
    -30 C to +80 C
    Operating Temperature
    -20 C to +70 C
  • Interface
    MIPI
    PIN
    30
  • Brightness (nits)
    400
    Active Area (mm)
    154.21 x 85.92
  • Outline Dimension (mm)
    195.8 x 125.61 x 8.25 (TLCM) / 165 x 100 x 5.3 (LCM)
    Resolution
    1024 x 600
  • Viewing Angle
    IPS
    Touch Panel
    CTP
  • Model No
    B24C70961Q-02-C
    Size
    7.0 inch

Technical Specifications

Size7.0 inch
Model NoB24C70961Q-02-C
Touch PanelCTP
Display TypeIPS
Resolution1024 x 600
Outline Dimension (mm)195.8 x 125.61 x 8.25 (TLCM) / 165 x 100 x 5.3 (LCM)
Active Area (mm)154.21 x 85.92
Brightness (nits)400
PIN30
InterfaceMIPI
Operating Temperature-20 C to +70 C
Storage Temperature-30 C to +80 C

Key Features

B24C70961Q-02-C is a 7.0-inch IPS TFT LCD display with 1024 x 600 resolution and a MIPI panel interface. The specified brightness is 400 nits. The module includes capacitive touch.

Applications

Industrial tabletsDrone remote control panelsSecurity & surveillanceMedical equipmentEV charging pilesOutdoor photography devices
BELIJ display application scenarios

Customization Options

  • Display size, resolution and brightness tailored to your project
  • Interface options: RGB / MIPI / LVDS / SPI, FPC or connector
  • Optional touch: resistive or capacitive (full lamination)
  • Custom cover glass, frame and structural design
  • Driver IC and backlight customization for special requirements
  • No MOQ for custom orders. Small-batch customization and mass production supported.

Dimensions

B24C70961Q-02-C dimensional drawing from datasheet

No Substitution. As Approved.
