B26C35075Q-05 – 3.5 Inch 320x480 MCU IPS TFT LCD Display
B26C35075Q-05 is a 3.5-inch IPS TFT LCD display with 320 x 480 resolution and a MCU panel interface. The specified brightness is 650 nits. Touch panel support is optional.
Product description
-
Storage Temperature-30 C to +80 COperating Temperature-20 C to +70 C
-
InterfaceMCUPIN24
-
Brightness (nits)650Active Area (mm)48.96 x 73.44
-
Outline Dimension (mm)54.5 x 82.9 x 2.05Resolution320 x 480
-
Viewing AngleIPSTouch PanelOptional
-
Model NoB26C35075Q-05Size3.5 inch
Technical Specifications
| Size | 3.5 inch |
|---|---|
| Model No | B26C35075Q-05 |
| Touch Panel | Optional |
| Display Type | IPS |
| Resolution | 320 x 480 |
| Outline Dimension (mm) | 54.5 x 82.9 x 2.05 |
| Active Area (mm) | 48.96 x 73.44 |
| Brightness (nits) | 650 |
| PIN | 24 |
| Interface | MCU |
| Operating Temperature | -20 C to +70 C |
| Storage Temperature | -30 C to +80 C |
Key Features
B26C35075Q-05 is a 3.5-inch IPS TFT LCD display with 320 x 480 resolution and a MCU panel interface. The specified brightness is 650 nits. Touch panel support is optional.
Applications
Industrial tabletsDrone remote control panelsSecurity & surveillanceMedical equipmentEV charging pilesOutdoor photography devices
Customization Options
- Display size, resolution and brightness tailored to your project
- Interface options: RGB / MIPI / LVDS / SPI, FPC or connector
- Optional touch: resistive or capacitive (full lamination)
- Custom cover glass, frame and structural design
- Driver IC and backlight customization for special requirements
- No MOQ for custom orders. Small-batch customization and mass production supported.
Dimensions
No Substitution. As Approved.
